PRODUCT DETAILS:

Pacemaker Headers to suit

Holden

HQ-HJ-HX-HZ-WB

283, 302, 305, 307, 327, 350, 400 V8 Small Block Chev Motor

Manual & Automatic

TRI-Y design



Important Notes

• Will fit Turbo 400 automatic

• Will fit Powerglide automatic

• Will not fit slant plug heads (Will need Part No. PH5315)

• Will not fit raised port heads

• Will only fit with original engine mounting spacers or PACEMAKER spacers part number Pemp 350 Note: spacers must be fitted on correct side of vehicle. (RH spacer is 1¾” high, LH spacer is 1¼” high)



Product Specs

Part #:	PH 5310
P/Steering:	Yes	Gasket:	DSF 9
Air Con:	Yes	Primary Pipe:	1⅝" (41mm)
Oxy Sen:	N/A	Secondary Pipe:	2" (51mm)
E.G.R:	N/A	Outlet:	2¼" (57mm)
Y Branch:	N/A	Fitting Time:	2 Hrs

***Disclaimer: Check over exhaust making sure everything is aligned and then tighten all bolts and nuts from the front to back of the vehicle. If you have any fitting/alignment issues, please call us as soon as possible to avoid damaging the exhaust system.***
